Prism Linear Outdoor Wall Sconce
A slim architectural outdoor wall fixture built for porches, entryways, garages, and facades. Die-cast aluminum housing with a high-translucent acrylic diffuser delivers even, glare-free light, while IP65 weatherproofing stands up to year-round outdoor exposure. Three sizes scale from compact accent to full-height architectural statement, with 5CCT tunable white or RGBCW smart color control.
Highlighted Features
How to Order
Select your model by length and control type. The example below shows the 16-inch 5CCT model at 277V. All models share the same 89mm wide body.
| JXL-BD16-BM15W-5CCT | 16", 15W, 500 lm, 5CCT |
| JXL-BD24-BM20W-5CCT | 24", 20W, 700 lm, 5CCT |
| JXL-BD24-BM20W-RGBCW | 24", 20W, RGBCW smart color |
| JXL-BD48-BM24W-5CCT | 48", 24W, 900 lm, 5CCT |
| D1 | 406 x 89 x 72.5 mm (16") |
| D2 | 610 x 89 x 72.5 mm (24") |
| D3 | 1200 x 89 x 72.5 mm (48") |
| 5CCT | 5-position tunable white |
| RGBCW | Full color + tunable white (Bluetooth/WiFi) |
| 100-277V | Universal AC input |
| CRI 90 | Color rendering index |
| IP65 | Weatherproof outdoor rated |
| cETL | Listed |
For full dimensional drawings and specifications, download the product spec sheet.
Download Full Spec SheetMore About the Prism Linear Sconce
Specifications at a Glance
| LED Type | SMD |
|---|---|
| Wattage | 15W / 20W / 24W |
| Lumens | 500 / 700 / 900 lm |
| CCT | 5CCT tunable (2700K–5000K) / RGBCW |
| CRI | Ra90 |
| Input Voltage | AC100-277V, 60Hz |
| IP Rating | IP65 |
| Dimming | Via app / Bluetooth (RGBCW mode); switch-selectable (5CCT mode) |
| Housing | Die-cast aluminum |
| Diffuser | High-translucent acrylic |
| Finish | Matte Black (AM) |
| Certification | cETL Listed (Intertek); IP65; RGB Listed |
Dimensions by Model
| Model | Length | Width | Depth |
|---|---|---|---|
| JXL-BD16-AM15W-5CCT | 406mm (16") | 89mm | 72.5mm |
| JXL-BD24-AM20W-5CCT | 610mm (24") | 89mm | 72.5mm |
| JXL-BD48-AM24W-5CCT | 1200mm (48") | 89mm | 72.5mm |
Size Guide: Which Length Is Right?
The JXL-BD series comes in three lengths designed for different architectural contexts:
| Model | Length | Best For |
|---|---|---|
| BD16 | 406mm / 16" | Compact accent: flanking a garage entry, single-column pillar, townhouse entryway |
| BD24 | 610mm / 24" | Standard statement: flanking a main entry door, residential porch post, mid-rise facade |
| BD48 | 1200mm / 48" | Full-height architectural: commercial facades, tall exterior walls, resort or hotel entrances |
For symmetrical flanking installations, two BD24 or BD48 units placed at eye level (center at roughly 1500–1800mm AFF) create a balanced architectural statement. The consistent 89mm width across all three sizes means a pair will always align cleanly.
CCT and RGBCW Color Control
The Prism Linear sconce is available in two color control modes:
5CCT Tunable White: Switch-selectable across five color temperatures — 2700K (warm candlelight), 3000K (warm white), 3500K (neutral), 4000K (cool white), and 5000K (daylight). Ideal for residential exteriors where a fixed warm tone is preferred, or commercial facades that need flexibility to match surrounding lighting without smart controls.
RGBCW Smart Control: Full red-green-blue-cool white spectrum with app or Bluetooth control. Set static colors, schedule color-changing scenes, or sync multiple fixtures. Best suited for hospitality exteriors, event spaces, accent facades, or any project where dynamic color is part of the design brief.
Note: CCT and RGBCW are separate SKUs. Specify at time of order.
Where to Use and Installation Tips
The Prism Linear Outdoor Wall Sconce is designed for exterior-mounted applications exposed to weather. IP65 certification means it handles direct rain, humidity, and condensation without compromise.
Suitable locations:
- Residential front entries and porch pillars
- Garage doors and driveways (flanking pairs)
- Commercial building facades and entrance canopies
- Outdoor corridors, breezeways, and covered walkways
- Retail storefronts and hospitality exteriors
Installation notes:
- Hardwired AC fixture — connect to a switched circuit or smart switch for on/off control
- For RGBCW models, pair with the compatible Bluetooth app or wireless controller
- Mount to an exterior electrical box (standard single-gang or octagon); 89mm body covers most standard box footprints
- Seal the wall penetration with outdoor-rated caulk to prevent moisture intrusion behind the fixture
- For flanking pairs, set fixture centers at the same height — typically 1500–1800mm above finished grade
Frequently Asked Questions
How do I read the order code?
The model number follows the pattern: JXL-BD[size]-BM[wattage]-[CCT mode]-[voltage]. For example, JXL-BD24-BM20W-5CCT-277 is the 610mm (24") model, 20W, 5CCT tunable white, 100-277V input.
What is the CRI of this fixture?
CRI Ra90 — colors rendered under this fixture appear natural and accurate, making it suitable for architectural details, landscaping, and facade materials where color quality matters at night.
Can I use this fixture outdoors year-round in a cold climate?
Yes. The IP65 rating and aluminum housing are suited for year-round outdoor exposure including Canadian winters. Confirm minimum operating temperature with the supplier for installations that see extreme cold below -20°C.
What is the difference between 5CCT and RGBCW?
The 5CCT model lets you select from five fixed color temperatures (2700K to 5000K) via a switch. The RGBCW model adds full color control via a Bluetooth app, enabling dynamic colors and scenes. Both share the same aluminum housing and IP65 rating.
Is this fixture dimmable?
The RGBCW model supports brightness control through the paired app. The 5CCT model's dimmability is not specified in the datasheet — confirm with C&C Lighting before specifying on a project that requires dimming.
What certifications does the Prism Linear Sconce carry?
cETL Listed (Intertek) for the Canadian and North American market, IP65 waterproof rated, and RGB Listed.
