Custom curved LED ring pendant light in matte black finish with warm 3000K illumination suspended on a seamless white studio background by C&C Lighting.

Customized Curved LED Linear Light

An architectural curved LED linear system that seamlessly splices straight lines and arcs into freeform shapes — ideal for commercial spaces, hospitality environments, offices, and large-scale custom ceiling designs.

8 Standard Shapes Custom Shapes Available 15×15mm to 150×30mm Profiles White & Black Finish cUL Listed
Download Spec Sheet

Highlighted Features

Innovative Curved Profile
Breaks through the traditional twisting process to achieve seamless splicing of straight lines and arcs. Transforms from two-dimensional to three-dimensional configurations, opening up new possibilities in linear lighting design.
Flexible Silicone Mask
Surface creatively applies a "flexible silicone mask" system. Straight and arc segments can be joined in any configuration using a continuous lampshade available in 50m and 100m rolls, eliminating splicing light leakage for a seamless overall effect.
Shape Variety
Eight standard model configurations available: CCL-1 through CCL-8. Options include circular rings, free-form curves, ellipses, multi-loop clusters, and angular geometric shapes. Custom shapes are available upon special request using the provided grid template.
Profile Dimension Options
Multiple profile cross-sections available — 15×15mm, 20×20mm, 35×35mm, and 50×35mm at 90° arcs; 30×30mm, 50×30mm, 80×30mm, and 150×30mm at 45° arcs. Larger 40mm-depth profiles also available up to 100×40mm for 90° configurations.
Radius & Diameter Range
90° arc radii range from R416mm (16.3") up to R1068mm (42.0") depending on profile size. 45° arc radii range from R261mm (10.2") up to R716mm (28.2"). Covers a wide span of architectural scales from intimate feature zones to grand lobby installations.
Modular Combination System
Straight line and arc foundation modules can be freely combined to form circular lamps, free-splicing curves, and custom multi-element configurations. Infinite design possibilities for both ceiling-mounted and suspended applications.
Finish Options
Available in White (W) or Black (B) as standard finishes. Custom colour options (O) are available — specify your desired colour when ordering. Finish is selected per project as part of the order configuration.
Custom Shape Ordering
For fully bespoke designs, select model choice C (Custom) and use the provided grid template to draw the desired shape with dimensions. Include preferred colour and all required measurements for manufacturing review.
Broad Application Range
Designed for commercial spaces including shopping malls, retail stores, and showrooms; hospitality environments such as hotels, lobbies, restaurants, and bars; public areas including airports, museums, and galleries; offices and modern residential interiors.
Certification
cUL Listed. Certified to Canadian and US standards for commercial and architectural lighting installations.
Three-Dimensional Design Freedom
The system enables flowing light to shuttle freely along ceiling planes in virtually any direction — deriving thousands of possible shapes from a core set of straight and arc modules, suitable for feature ceilings of any scale or complexity.
Manufacturer
Designed and distributed by C&C Lighting, based in Concord, Ontario, Canada. Contact: info@candclight.com | 1-905-856-0903. Available for commercial projects across Canada and the US.
