3D Flex Wall Washer LED Strip
A dual-bending flexible LED strip that bends from both the top and the side, giving you traditional wall washing along with curved surfaces and general home lighting from a single product. Built with a food class silicone tube and an ABS injection shell rated UL94-V0.
DC24V 16W / 1600LM per Meter 48pcs SMD2835/Meter CRI 90 IP67 Rated UL/CE/RoHS/UKCA Certified
Download Spec Sheet
Highlighted Features
Fixture Type
Flexible LED wall washer strip designed for both top bending and side bending, a two-in-one function that lets a single strip handle traditional wall washing as well as curved surface and home lighting applications.
Input Voltage
Operates on DC24V, suited for low-voltage residential and commercial installations where a compatible driver is used.
Output Configuration
Item NS-2835-48-24 delivers 16W and 1600LM per meter, with 48pcs SMD2835 LEDs per meter across a 5 meter roll, for consistent and continuous illumination along the full run.
Color Temperature and Beam Angle
Available in 2700K, 3000K, 4000K, and 6000K. Beam angle of 30 degrees, or 30 by 45 degrees depending on configuration, with a CRI of 90 for accurate color rendering.
Bending Function
Engineered to bend both at the top and along the side, a two-in-one design that achieves the wall washing effect of a traditional LED strip while also adapting to curved surfaces and architectural details.
Construction
Food-class silicone tube material that is UV-resistant, paired with an ABS injection shell rated UL94-V0 for fireproofing. Strip dimensions are 16mm by 16mm, with a net weight of 0.85kg per 5 meter roll.
Waterproofing
IP67 rated for protection against dust and temporary water immersion, suitable for damp and exterior locations within the specified operating range.
Operating Conditions
Operating temperature range of -25°C to +45°C. Storage temperature range of -30°C to +80°C, supporting reliable performance across a wide range of installation environments.
Safety and Certification
CE and RoHS certified for stable, reliable operation. Additional certification coverage includes UL and UKCA.
Roll Specification
Supplied in 5 meter rolls at 0.85kg net weight per roll, item number NS-2835-48-24.
Warranty
Backed by a 3 year warranty for dependable performance in wall washing, curved surface, and home lighting applications.
