C&C Lighting LED Bollard Light BR06 Series — all seven interchangeable head styles in black finish displayed side by side: BR06A cone reflector flat top, BR06B cone reflector dome top, BR06C louvered reflector flat top, BR06D louvered reflector dome top, BR06E decorative wide top, BR06F decorative low-profile flat top, BR06G decorative low-profile flat top — die-cast aluminum housing, IP65 rated, UL Listed, available in 24-inch 30-inch 36-inch and 42-inch heights

BR06 LED Bollard Light

A UL Listed outdoor LED bollard available in 24", 30", 36", and 42" heights with seven interchangeable head styles and a 3-in-1 switch for field-selectable CCT, wattage, and dusk-to-dawn photocell control.

24" / 30" / 36" / 42" 14W / 19W / 24W 120–347VAC Input 3CCT Selectable IP65 Rated UL Listed
Download Spec Sheet

Highlighted Features

Fixture Type
Outdoor LED bollard designed for walkways, entrance ways, driveways, and residential and commercial landscape applications. Available in seven interchangeable head styles — cone reflector, louvered reflector, and decorative — on a shared housing in black or bronze finish.
Input Voltage
Universal input voltage of AC 120–277V standard, or AC 120–347V for Canadian three-phase systems. Compatible across residential and commercial electrical installations throughout North America.
Interchangeable Head Styles
Seven bollard heads share a single housing to reduce SKU count and simplify project fulfillment: BR06A and BR06B (cone reflector, flat and dome top), BR06C and BR06D (louvered reflector, flat and dome top), and BR06E, BR06F, and BR06G (decorative). PIR sensor optional.
Field-Selectable Wattage and CCT
3-in-1 onboard switch allows field selection of wattage (14W, 19W, or 24W) and CCT (3000K, 4000K, or 5000K) without rewiring. Ships preset at the highest wattage and highest CCT. A single SKU covers a wide range of project specifications.
Photocell Control
Integrated D2D photocell automatically turns the fixture off at sunrise and on at sunset. Photocell on/off is controlled via the 3-in-1 switch. Factory default is photocell ON.
Dimming
0-10V dimming supported across all models. Power factor is 0.90 or greater. Emergency driver versions support 1-10V dimming and are available as a separate accessory for compatible configurations.
Efficacy and Light Output
Up to 140 lm/W efficacy on BR06A and BR06B models. Measured lumen output at 24W ranges from 1,600 lm (BR06C/D) to 3,300 lm (BR06A/B). BR06E, BR06F, and BR06G deliver 2,800 lm at 24W. All values measured at 5000K. CRI greater than 80 on BR06A through BR06E; CRI greater than 70 on BR06F and BR06G.
Optics
Type V wide beam distribution suited for pathway and area lighting. Polycarbonate lens on all models for impact resistance and long-term optical clarity in outdoor environments.
Construction
ADC12 die-cast aluminum housing with polycarbonate lens. Available in black or bronze finish. IP65 waterproof rated. IK08 impact rated. Operating temperature range of -40°C to +50°C for standard models.
Safety and Certification
UL Listed. DLC Premium listed (DLC pending for BR06C and BR06D). IP65 waterproof rated, IK08 impact rated. Surge protection L/N 4KV and L/N-P 4KV. THD less than 20%. RoHS compliant.
Accessories
Retrofit plate in black or bronze (ACC-BR06-RT), 180° spill shield for BR06A through BR06D (ACC-BR06-SS), 4W Helpower emergency driver (EMY-04150DO-U3), 10KV surge protectors for AC120-277V (ZYS-P10A) and AC120-347V (ZYS-P10M), and optional Mosentek PIR sensor (MS018). All accessories sold separately.
Warranty
Backed by a 5-year limited warranty for dependable performance in commercial and residential outdoor lighting applications.
