C&C Lighting Ansel slim black LED picture light with a long frosted light bar, a hinge on the top edge and a compact black wall box, glowing warm white

Ansel Picture Light

The C&C Ansel Picture Light is a slim, frosted LED bar in a black housing, carried on a short arm from a compact wall box. A hinge at the top of the bar lets it articulate up and down, so you can aim the light where you want it. Use it above artwork, mirrors, headboards or shelving for a soft, even wash of light.

110-120V 20W LED 3000K / 4000K / 5000K Triac dimmable Hinged bar ETL listed Dry locations
Download Spec Sheet

Highlighted Features

Articulating Bar
A top hinge tilts the light bar up and down, so you can aim the light at the wall or the artwork.
Frosted Light Bar
A frosted diffuser spreads the light softly and evenly along the bar.
Slim Black Profile
A slim rectangular bar with small end caps gives a clean, architectural line.
Compact Wall Box
A small black wall box and short arm hold the bar clear of the wall.
Selectable CCT
Choose 3000K, 4000K or 5000K to match the space.
Integrated LED
A built-in 20W LED source, with no lamps to replace.
Dimmable
Dims on a compatible triac (forward-phase) dimmer.
Certified
ETL listed to UL 1598 and CSA C22.2 No. 250.0, for dry locations.

How to Order

The Ansel Picture Light is a single wall-mounted fixture. To place an order, contact us at info@candclight.com with your project name, quantity and the dimmer you plan to use.

C&C-25037-B01A-BK

Model
Voltage
110-120V AC input, 50/60Hz
Power
20W LED
LED Integrated
Color Temperature
3000K Selectable
4000K Selectable
5000K Selectable
Listing
ETL Listed (cETLus)
Dry Locations only

For full technical specifications, download the product spec sheet.

Download Spec Sheet

More About the Ansel Picture Light

Specifications at a Glance
Model C&C-25037-B01A-BK
Input voltage 110-120V AC, 50/60Hz
Power 20W LED
Light source Integrated LED
Color temperature 3000K / 4000K / 5000K selectable
Driver Constant current, Class 2
Driver output 500mA, 18-40VDC
Power factor Above 0.90 at 120V
Dimming Triac, at 120V
Form Frosted LED bar on hinged arm with wall box
Finish Black
Mounting Wall
Location rating Dry locations only
Certification ETL listed (cETLus)
Standards UL 1598, CSA C22.2 No. 250.0
Design and Finish

The name Ansel nods to the photographer known for his mastery of light. A slim black bar with small end caps and a frosted diffuser sits on a short arm from a compact black wall box. A small hinge at the top of the bar joins the two, so the bar can articulate up and down.

The matte black finish stays quiet against plaster, paint, timber and stone, so the light and the artwork take the focus.

Driver, Dimming and Color Temperature

Ansel uses a constant current, Class 2 LED driver with a 500mA, 18-40VDC output and a power factor above 0.90 at 120V. It is rated for 110-120V at 50/60Hz, and the integrated LED is 20W.

Color temperature is selectable at 3000K, 4000K or 5000K, so one fixture can be tuned to each room. The driver is dimmable at 120V on a compatible triac (forward-phase) dimmer. Dimming performance depends on the dimmer, so please confirm compatibility before ordering. Installation should be completed by a qualified electrician in accordance with local electrical codes.

Where to Use It
  • Artwork and galleries: mount above a painting or print for a soft, even wash of light.
  • Mirrors and consoles: add gentle light above a mirror, sideboard or entry console.
  • Bedrooms and studies: light a headboard wall, desk wall or bookshelf.
  • Hotel rooms and boutique hospitality: a refined, consistent wall light for guest rooms and shared spaces.

Ansel is rated for dry locations only and is intended for indoor use.

Frequently Asked Questions

What voltage does the Ansel use?
110-120V AC, 50/60Hz, for North American projects.

What is the wattage?
20W, with an integrated LED.

Can I choose the color temperature?
Yes. It is selectable at 3000K, 4000K or 5000K.

Is it dimmable?
Yes, at 120V on a compatible triac (forward-phase) dimmer. Please confirm compatibility with your specific dimmer.

Can the light bar be adjusted?
Yes. A hinge at the top of the bar lets it articulate up and down. Please contact us for details on the range of movement.

Is it certified?
Yes. It is ETL listed (cETLus) to UL 1598 and CSA C22.2 No. 250.0, for dry locations.

Can I use it in a bathroom or outdoors?
Ansel is rated for dry locations only. Please contact us if you are unsure whether a space qualifies.

Where can I find size details?
Contact us at info@candclight.com and we will confirm dimensions for your project.
