C&C Lighting LED Wall Mount Cylinder WP29 4-inch model WP29-4-20M-S2D3C3 — bronze die-cast aluminum housing with polycarbonate lens, wall mount plate, and integrated photocell — 20/16/12W selectable, 3CCT selectable 3000K/4000K/5000K, beam angle 25/40/60 degrees selectable, up/full/down lighting direction, 0-10V dimming, IP65 rated, UL Listed, wet location rated

WP29 LED Wall Sconce

A UL Listed outdoor wall cylinder available in 3-inch, 4-inch, and 6-inch sizes with field-selectable CCT, beam angle, wattage, and lighting direction — plus a built-in dusk-to-dawn photocell for automated on/off control.

3" / 4" / 6" 10W / 20W / 36W 120–347VAC Input 3CCT Selectable IP65 Rated UL Listed
Download Spec Sheet

Highlighted Features

Fixture Type
Outdoor LED wall mount cylinder designed for facades, entryways, awnings, and wall washing applications. Available in 3-inch, 4-inch, and 6-inch diameter sizes in a standard bronze finish with an optional square shell accessory.
Input Voltage
Universal input voltage of 120–347VAC, 50/60Hz for broad compatibility across residential and commercial electrical systems throughout North America.
Output Configurations
Three size and wattage configurations: 3-inch at 10/8/6W (WP29-3-10M-S2D3C3), 4-inch at 20/16/12W (WP29-4-20M-S2D3C3), and 6-inch at 36/28/21W (WP29-6-36M-S2D3C3). All models offer field-selectable wattage via onboard DIP switch.
Selectable CCT and Beam Angle
Field-adjustable CCT across three settings — 3000K, 4000K, and 5000K — and three beam angles — 25°, 40°, and 60° — selectable via onboard DIP switch. Factory default is 4000K at 40°. Allows a single SKU to serve multiple project specifications.
Lighting Direction
DIP switch-selectable lighting direction: Up only, Full (up and down), or Down only. Enables precise control of facade illumination, wall washing, and accent lighting effects from a single fixture.
Photocell Control
Standard integrated dusk-to-dawn D2D photocell automatically turns the fixture off at sunrise and on at sunset. Photocell is enabled by default and can be switched off via the onboard control panel.
Dimming
0-10V dimming standard across all models. The 4-inch and 6-inch EM versions also support 1-10V dimming for emergency lighting compatibility. Power factor is 0.90 or greater across all configurations.
Efficacy
Delivers up to 150 lm/W efficacy across all three sizes. Measured lumen output at full direction ranges from approximately 906 to 1,448 lm for the 3-inch, 1,826 to 2,958 lm for the 4-inch, and 3,334 to 5,570 lm for the 6-inch, depending on wattage, CCT, and beam angle. CRI greater than 80.
Construction
6063 aluminum housing with die-cast aluminum end caps and mounting plate. Polycarbonate lens. Bronze finish standard. IP65 waterproof rated for wet location use. Operating temperature range of -40°C to 45°C.
Safety and Certification
UL Listed for wet location use. IP65 waterproof rated. Surge protection of L/N 2KV and L/N-P 4KV on 10W and 20W models; L/N 4KV and L/N-P 6KV on the 36W model. RoHS compliant.
Accessories
Optional square shell accessories available for all three sizes (ACC-WP29-3-SS, ACC-WP29-4-SS, ACC-WP29-6-SS) in bronze finish. A 4W Helpower emergency driver (EMY-04058D0-HY) is available separately for 4-inch and 6-inch fixtures. All accessories sold separately.
Warranty
Backed by a 5-year limited warranty for dependable performance in commercial and residential outdoor lighting applications.
